Shandong Ningye Machinery Equipment Co., Ltd. yog ib qho ntawm cov ua lag luam thiab cov chaw muag khoom ntawm cov dej khib nyiab sludge scraper hauv Suav teb. Nrog ib pab neeg tsim khoom, peb muaj peev xwm ua tau raws li qhov xav tau ntawm feem ntau ntawm peb cov neeg siv khoom. Thov koj xav tias dawb mus yuav cov dej khib nyiab ruaj khov sludge scraper ntawm tus nqi qis los ntawm peb lub hoobkas.
Cov Khoom Siv Hluav Taws Xob Cov Hluav Taws Xob Sludge Scraper yog cov khoom siv tshem tawm cov sludge uas siv rau hauv cov dej khib nyiab thib ob thiab thawj cov dej khib nyiab ntawm cov chaw kho dej khib nyiab. Peb lub tuam txhab yog cov chaw tsim khoom nrog ntau xyoo ntawm kev tsim thiab kev tsim khoom. Peb cov khoom lag luam npog cov khoom siv hluav taws xob sab nraud, nruab nrab tsav, saw-hom, thiab siphon- hom qauv. Cov cuab yeej sau cov sludge nyob rau hauv qab ntawm lub tank thiab thawb nws mus rau lub qhov hluav taws xob sludge tawm, kom ntseeg tau tias cov dej tsis zoo.
Hom loj
|
Hom |
Daim ntawv thov |
Nta |
|
Peripheral Drive Scraper |
Loj ncig sedimentation tso tsheb hlau luam (inch 10m-60m) |
Siab torque, ruaj khov ua haujlwm, haum rau cov tank loj |
|
Center Drive Scraper |
Me me ncig lub tso tsheb hlau luam (inch 6m-25m) |
Compact qauv, yooj yim installation, me me hneev taw |
|
Chain -Hom Scraper |
Rectangular sedimentation tanks |
Muaj zog yoog raws, ua haujlwm siab -cov kua qaub |
|
Ncig Saib Choj Scraper |
Loj rectangular sedimentation tanks |
Dav dav, thaj tsam loj ntawm ib chav tsev |
Cov Qauv Txheej Txheem
Drive Unit:
Reducer + lub cev muaj zog. Explosion- pov thawj lub cev muaj zog muaj. Kev tiv thaiv qib IP55 thiab siab dua.
Scraper caj npab:
Cov pa roj carbon steel nrog tiv thaiv -corrosion txheej. Stainless hlau xaiv muaj.
Scraper Hniav:
Polyurethane los yog cov khoom siv roj hmab. Kev sib cuag siab nrog lub tank hauv qab. Hnav-resistant.
Sludge Pipe / Sludge Hopper:
Stainless hlau. Txuas nrog sludge qhov hluav taws xob los coj cov dej ntws tawm.
Center Support / End Support:
Dais tag nrho qhov hnyav ntawm lub tshuab. Rotating qhov chaw siv coj-cov kabmob tiv taus.
Tswj System:
Txhawb phau ntawv / pib hloov. Nws tuaj yeem txuas nrog PLC rau kev tswj chaw taws teeb.
Technical Parameters (Peripheral Drive Scraper ua piv txwv)
|
Parameter |
Ntau yam |
|
Tank Diameter |
6m – 60m |
|
Tus nqi ntws |
500m³/h – 50,000m³/h |
|
Scraper Linear Ceev |
0.5-3.0m / min |
|
Lub cev muaj zog |
0.75 kW - 7.5 kW |
|
Tank Qhov tob |
2.5m – 6.0m |
|
Khoom siv |
Carbon Steel + Anti-corrosion / SS304 / SS316L |
|
Qib tiv thaiv |
IP55 / IP65 |
Core Zoo
Direct Chaw tsim tshuaj paus, Tsis muaj Middleman:
Peb tswj tag nrho cov txheej txheem los ntawm kev tsim, machining, thiab sib dhos mus rau commissioning. Lub sij hawm xa tuaj yog lav.
Strong Customization Muaj peev xwm:
Peb muab ib qho - rau- ib qho kev tsim qauv daws teeb meem raws li koj lub tank qhov ntev, sludge concentration, thiab qhov chaw nyob.
Cov khoom siv dav dav:
Cov pa roj carbon steel nrog epoxy txheej, SS304, SS316L - muaj los ua kom tau raws li cov kev xav tau sib txawv.
Replaceable Scraper Hniav:
Polyurethane hniav tuaj yeem hloov tau ib tus zuj zus thaum hnav, txo cov nqi tu.
Torque Verified los ntawm xam:
Txhua chav ua haujlwm dhau qhov kev kuaj xyuas ua ntej tawm hauv lub hoobkas kom tsis txhob muaj qhov tsis txaus torque ntawm qhov chaw.
Ua kom tiav cov ntaub ntawv Technical:
Xws li kev teeb duab kos duab, daim duab kab hluav taws xob, thiab cov ntawv ua haujlwm & kev saib xyuas.
Daim ntawv thov Scenario
- Municipal wastewater kho nroj tsuag (thawj thiab theem nrab sedimentation tanks)
- Muaj chaw kho dej khib nyiab (electroplating, dyeing, zaub mov, tshuaj industries)
- Cov dej ua haujlwm sedimentation tanks
- Sludge thickening tanks hauv ntawv-ua thiab tanning industries
Tom qab -Kev Pabcuam Muag
- Ntawm - qhov kev taw qhia kev teeb tsa chaw muaj. Cov kws kho mob tuaj yeem xa mus rau commissioning.
- Ntev -Lub sij hawm muab khoom ntawm cov khoom hnav: scraper hniav, bearings, seals, thiab lwm yam.
- 24-teev technical support teb.
Cov ntaub ntawv xav tau rau kev xaiv
Txhawm rau muab cov lus hais kom raug thiab kev daws teeb meem, thov muab cov hauv qab no:
- Tank duab (lub voj voog / duab plaub) thiab qhov ntev (inch lossis L × W)
- Siv dej tob
- Tsim tus nqi ntws
- Sludge zog (cov ntsiab lus noo noo, concentration)
- Ntawm -qhov chaw fais fab mov (voltage, zaus)
- Seb yuav tsum tau tswj tej thaj chaw deb interface
